GTX 10Wi TWO-WAY LINE ARRAY MODULE - TT Audio

ADVANCED CORE TECHNOLOGY
Innovative design refinements enable our new True Resistive Waveguide to provide effective driver loading and precise pattern control for transducers. Designed with Finite Element Analysis and proven in RCF’s anechoic chambers, the 4PATH technology produces an ideal isophasic load with low distortion and coherent phase response, even at the lowest crossover frequencies.
THE POWER OF SYMMETRY
The symmetrical enclosure design and component topology produce consistent coverage from left to right. Symmetrical component positioning and special DSP crossover filtering provide constant directivity and perfect continuity of the hemicylindrical wave directivity without lobes and discontinuities. Frequency modulations are avoided by the optimized active crossover design.


HIGH FREQUENCY
The 4-inch titanium dome compression drivers, equipped with high-current neodymium magnets, are designed to fully leverage the remarkable capabilities of the TRW-4PATH waveguide. As a result, the GTX10Wi 110° x 30° coverage is finely matched with the output of its woofers for perfect phase coherence.
LOW FREQUENCY
The low distortion, high output design of the two 10” HyperVented woofers ensures superb fidelity and high dynamic range. With 3.0” inside-outside voice coils and high flux density neodymium magnets, the fast, high-stiffness motor section provides high impact low-frequency reproduction.

ENCLOSURE AND RIGGING HARDWARE
The sturdy, weather-resistant birch multi-ply enclosure features optimized hardware for safety and adaptability, including a rear mechanism for angle selection. High-strength Strenx steel rigging hardware ensures secure deployment of up to 16 modules in tension or compression mode. Power connection is provided via a watertight screw terminal connection panel designed for cables up to AWG 9. The powder-coated protective grille includes a protective foam layer. For enhanced weather resistance, the IP version offers an additional acoustically transparent, water-repellent fabric.
CERTIFIED SYSTEM COMPLIANT WITH EN 54
Engineered to meet one of the most stringent international standards for voice-alarm and emergency communication systems, GTX 10i ensures reliable operation under critical conditions. The EN 54-24:2008 certification verifies compliance with the demanding acoustic, mechanical, and environmental requirements defined for life-safety installations.

TT+ AUDIO products are continually improved. All specifications are therefore subject to change without notice.
