GTX 10

TWO-WAY LINE ARRAY MODULE

143 dB max SPL

4” titanium dome, neo compression driver

2 x 10” neo woofers, 3” v.c.

110° x 15° 4PATH waveguide

Designed to operate with XPS 16K amplifier (up to 6 modules per amp unit)

Durable and lightweight cabinet construction, polyurea coating

Heavy duty, powder coated, custom perforated front grille

3 x P-COM 8 pole bayonet connectors (Gold coated, CA-COM compatible, IP 68)

TOURING

GTX 10

TWO-WAY LINE ARRAY MODULE

143 dB max SPL

4” titanium dome, neo compression driver

2 x 10” neo woofers, 3” v.c.

110° x 15° 4PATH waveguide

Designed to operate with XPS 16K amplifier (up to 6 modules per amp unit)

Durable and lightweight cabinet construction, polyurea coating

Heavy duty, powder coated, custom perforated front grille

3 x P-COM 8 pole bayonet connectors (Gold coated, CA-COM compatible, IP 68)

The GTX 10 is a 2-way line array module for medium to large-scale, high-demanding touring and install applications, indoors and outdoors. Equipped with three best-in-class transducers, it offers excellent reproduction quality and optimized directivity. Up to 24 GTX 10 modules can be suspended on a single fly-bar.

SUGGESTED CONFIGURATIONS

TEN OUT OF TEN

TOUR-WORTHY WORKHORSE

The GTX 10 is the solution for medium-sized events where high scalability and fast deployment are required. While the GTX system is already the epitome of quality in the TT+ AUDIO catalog, the GTX 10 line array incorporates this philosophy fully, providing remarkable power and extreme clarity in a small and fast-to-deploy package.

THE POWER OF SYMMETRY

The symmetrical enclosure design and component topology produce consistent coverage from left to right. Symmetrical component positioning and special DSP crossover filtering provide constant directivity and perfect continuity of the hemicylindrical wave directivity without lobes and discontinuities. Frequency modulations are avoided by the optimized active crossover design.

HIGH FREQUENCY

The 4-inch titanium dome compression drivers, equipped with high-current neodymium magnets, are designed to fully leverage the remarkable capabilities of the TRW-4PATH waveguide. As a result, the GTX10’s 110° x 15° coverage is finely matched with the output of its woofers for perfect phase coherence.

LOW FREQUENCY

The low distortion, high output design of the two 10” HyperVented woofers ensure superb fidelity and high dynamic range. With 3.0” inside-outside voice coils and high flux density neodymium magnets, the fast, high-stiffness motor section provide high impact low frequency reproduction.

ENCLOSURE AND RIGGING HARDWARE

The sturdy weather-resistant birch multi-ply enclosure with durable polyurea coating features optimized hardware for speed and efficiency, with a rear hinge bar mechanism that slips into the angle preset position when hoisting the array. The optional cart (Model# KRT-WH 002) allows for the transport of four GTX 10 enclosures, with custom-designed protective covers for safe handling.

Part number

13000796
GTX 10
EAN 8024530021153

Spezifikation

Frequenzgang (-10dB)

42 Hz - 20000 Hz

Max SPL @ 1m:

143 dB

Horizontaler Abstrahlwinkel:

110°

Vertikaler Abstrahlwinkel:

15°

Power sektion

Amplification

Bi-Amp

Nominalimpedanz LF

8 ohm

Nominalimpedanz HF

8 ohm

Schallwandler

Kompressionstreiber:

1 x 1.4'' neo, 4.0'' v.c

Woofer

2 x 10'' neo, 3.0'' v.c

Input/Output sektion

Eingangsbuchsen

P-COM 8POLE

Ausgangsanschlüsse

P-COM 8POLE

Standardkonformität

Safety agency

CE compliant

Physikalische daten

Gehäuse Material

Birch plywood

Hardware

Array fittings

Griffe

1 x side, 2 rear

Gitter

Steel with clothing

Farbe

Black

Größe / Gewicht

Höhe

337 mm / 13.27 inches

Breite

750 mm / 29.53 inches

Tiefe

483.5 mm / 19.04 inches

Gewicht

31.5 kg / 69.45 lbs

Versandinformationen

Verpackung Höhe

539 mm / 21.22 inches

Verpackung Breite

787 mm / 30.98 inches

Verpackung Tiefe

382 mm / 15.04 inches

Verpackungsgewicht

33.2 kg / 73.19 lbs
